151 / 190
● MACHINE ●
CARTONING MACHINE VERTICAL 120 BPM
Model No.CVC120
A cost effective choice of cartoning machine. It's driven by one motor to coordinate all mechanisms. Easy maneuver; low maintenance. Various optional accessories available.
| SPEED | Max. 120 BPM |
| BOX SIZE | 50~200 (L) x 30~100 (W) x 25~80 (H) (m/m) |
| AIR PRESSURE | 5 (Kg/cm²) |
| POWER SUPPLY | 3Ø 220V 50/60HZ 1.5KW |
| MACHINE SIZE | 4010 (L) x 2020 (W) x 1825 (H) (m/m) |
152 / 190
● MACHINE ●
CARTONING MACHINE FOR BLISTER PACKS
Model No.CHS120
With intermittent structure, it's built with 3-axis servo control system with easy set up and maintenance. Average speed 60 BPM.
| SPEED | 60 BPM |
| BOX SIZE | 70~180 (L) x 60~120 (W) x 30~100 (H) (m/m) |
| AIR PRESSURE | 5 (Kg/cm²) |
| POWER SUPPLY | 3Ø 220V 50/60HZ 5.5KW |
| MACHINE SIZE | 2800 (L) x 1050 (W) x 1725 (H) (m/m) |
153 / 190
● MACHINE ●
Cartoner Super High Speed (Horizontally insert contents)
Model No.CHC120
A cartoner that's driven by one motor for all mechanisms. It is designed to enhance PTP production to reach speed up to 300 box per minute.
| SPEED | Max. 300 BPM |
| BOX SIZE | 35 ~ 100 (L) x 20 ~ 80 (W) x 20~80 (H) (m/m) |
| AIR PRESSURE | 5 (Kg/cm²) |
| POWER SUPPLY | 3Ø 220V 50/60HZ 5.5KW |
| MACHINE SIZE | 4420 (L) x 1530 (W) x 1510 (H) (m/m) |
154 / 190
● MACHINE ●
Shrink Sleeving
Model No.LE100 + Heat Tunnel
Main parts are constructed quality SUS304 or SUS316 to guarantee safety requirement for food, drink, and healthcare products.
Built to provide a wide range of application to accommodate different products. User friendly HMI provides easy maneuver settings. Minimal maintenance requirement. een can be saved several memories for easy work.
Built to provide a wide range of application to accommodate different products. User friendly HMI provides easy maneuver settings. Minimal maintenance requirement. een can be saved several memories for easy work.
155 / 190
● MACHINE ●
COMPLETE FLOW WRAPPING MULTI LAYER FOR YOGURT DRINK
Model No.PSA250N
There are 2 model of Horizontal Flow Wrappers. One is PSA-250N for non-shrinkable film, another one is PSA-250W for heat shrink film. Both are built to shrink wrap products with multi layers at high speed, 80 Packs Per Minute.
Machine Dimension: 4720 (L) x 850 (W) x 1650 H) (m/m) |
156 / 190
● MACHINE ●
Rinsing Machine for Large Glass Jars
Model No.BA5600
A large sized glass jars rinsing machine that's built with multi nozzles to cleanse containers before filling. Speed up to 100 BPM. Its bottle inversion design completely removes dusts. It can be customized to cleanse bottles by water or by air.
| Speed | 40 ~ 100 BPM |
| Container Material | Glass, Plastic |
| Bottle Diameter | 69 ~ 120 mm |
| Neck Opening | 25 ~ 100 mm |
| Contain Total Height | 45 ~ 100 mm |
| Power Supply | 110VAC or 220 VAC |
| Machine Size | (L) 3000mm (W) 1000 mm (H) 1800 mm |
| Machine Weight | 450 kg (993 lbs) |
* Subj to Testing ** Subj to Product Types & Sizes *** Customizable + Transparent Subj to Different Sensor Charge ++ Non Standard Sizes Subj to Additional Charge +++ Subj to Extra Parts | |
157 / 190
● MACHINE ●
Horizontal Flow Wrapper
Model No.PSA200N
A space saving wrapping machine to completely wrap your products. It closes the bags with precision cutting and sealing.
* Machine Dimension: |
158 / 190
● MACHINE ●
Tabletop Top Labeler
Model No.LT1100
A simple semi automatic top labeler. It's controlled by a micro-computer with built-in parameter settings that help eliminate complicated setup time.
|
159 / 190
● MACHINE ●
CRIMPER FOR VIALS
Model No.BAL5020
Manual crimper for sealing aluminum caps. Made of quality craftsmanship and materials for precision and longevity.
160 / 190
● MACHINE ●
Double Capping System for Inner & Outer Caps
Model No.CP7100 CS7100
It's a system that efficiently handles the capping process of a packaging operation. Bottles are firmly held by custom molded starwheels ready for capping. Four cap-feeding devices automatically feed both the inner caps and outer caps to be ready for pressing down and screw tightening actions. Double conveyors move forward two lines of bottles from one station to the next.
| Speed | 45 ~ 75 BPM ** |
| Cap Type | Plastic or Aluminum * |
| CAP DIAMETER OUTER | 20 ~ 110 mm *** |
| BOTTLE HEIGHT | 50 ~ 150 mm |
| AIR COMPRESSOR | 30 ~ 100 mm |
| POWER SUPPLY | 2 ~ 5 Kg |
| MACHINE SIZE LxWxH | 110 or 220 VAC; 50/60 Hz; single phase |
| MACHINE WEIGHT | L 5128 x W 1445 x H 1745 mm |
| 950 kg | |
* Subj to Testing ** Subj to Product Types & Sizes *** Customizable + Transparent Subj to Different Sensor Charge ++ Non Standard Sizes Subj to Additional Charge +++ Subj to Extra Parts | |
