LABELING

Affordable Automation Made Easy

1 / 7
Vertically & horizontal apply labels
Video Specs

Label Small Vials & Lab Test Tubes

Model No.LABELERS - VERTICAL & HORIZONTAL
2 / 7
Labeling small tubes
Video Specs
3 / 7
Wrap around labeler
Video Specs
4 / 7
Click to view machine in operation.
Video Specs Features Options

Labeling: Double Labels on One Side & Gripper Conveyor to Allow Bottom Coding (Large Label Size)

Model No.LD3000
It's a side labeling system design to give smooth application, precise timing, and perfectly centered position for large sized labels. It connects with a gripper conveyor to allow for easy bottom coding.
SPECIFICATIONS
Speed 20 ~ 40 BPM **
Bottle Size ++ Dia.15~90 mm/ Height 30~160 mm
Label Type + Non Transparent
Label Size ++ H 10~100mm W 20~300mm
Label Reel ID 75 / OD < 300 mm
Accuracy +/- 1%
Power Supply 10VAC or 220VAC, Single Phase
Machine Size L1800 x W1540 x H1824 mm
Machine Weight 100 kg
* Subj to Testing
** Subj to Product Types & Sizes
*** Customizable
+ Transparent Subj to Different Sensor Charge
++ Non Standard Sizes Subj to Additional Charge
5 / 7
3 Sides Labeler
Video Specs Features Options

Labeling: 3 Sides Labeler

Model No.LD3055
Applying labels from the side to cover three sides of a container. Controlled by microprocessor and electronic sensing system.
SPECIFICATIONS
Speed 40 PPM *
Bottle Size ++ Dia. 20~100 mm/ Height 25~80mm
Label Type + Non Transparent
Label Size ++ W10~100 x H20~300 mm
Label Reel ID 75 / OD < 300 mm
Accuracy +/-1 mm
Power Supply 110VAC or 220VAC, Single Phase
Machine Size L2100 x W1380 x H1500 mm
Machine Weight 125 kg
* Subj to Testing
** Subj to Product Types & Sizes
*** Customizable
+ Transparent Subj to Different Sensor Charge
++ Non Standard Sizes Subj to Additional Charge
6 / 7
Horizontal Labeler Plus Side Labeler
Video Specs Features Options

Labeling: Horizontal Labeler Plus Side Labeler

Model No.LR460S
Labels can be applied onto the entire surface of a cylindrical objects. An applicator can be added to apply labels from the side or from the bottom.
SPECIFICATIONS
Speed 80 ~ 150 PPM *
Bottle Size ++ Dia. 9.5~25mm/ Height 30~160mm
Label Type + Non Transparent
Label Size ++ W10~100 x H20~300 mm
Label Reel ID 75 / OD < 300 mm
Accuracy +/-1 mm
Power Supply 110VAC or 220VAC, Single Phase
Machine Size L610 x W730 x H1500 mm
Machine Weight 115 kg
* Subj to Testing
** Subj to Product Types & Sizes
*** Customizable
+ Transparent Subj to Different Sensor Charge
++ Non Standard Sizes Subj to Additional Charge
7 / 7
3 Sides Labeler for Square Container
Video Specs Features Options

Labeling: 3 Sides with Additional Top Label

Model No.LR3055 + Additional Top Label
A labeling system covers three sides plus a top labeling. It requires very minimal maintenance and simple adjustment for smooth operation.
SPECIFICATIONS
Speed 20~60 PPM *
Bottle Size ++ Dia. 20~100 mm/ Height 25~80mm
Label Type + Non Transparent
Label Size ++ W20~100 x H25~80 mm
Label Reel ID 75 / OD < 300 mm
Accuracy +/-1 mm
Power Supply 220VAC, Single Phase
Machine Size L1400 x W750 x H1500 mm
Machine Weight 115 kg
* Subj to Testing
** Subj to Product Types & Sizes
*** Customizable
+ Transparent Subj to Different Sensor Charge
++ Non Standard Sizes Subj to Additional Charge
