Labeling: Double Labels on One Side & Gripper Conveyor to Allow Bottom Coding (Large Label Size)
Model No.LD3000
It's a side labeling system design to give smooth application, precise timing, and perfectly centered position for large sized labels. It connects with a gripper conveyor to allow for easy bottom coding.
| Speed | 20 ~ 40 BPM ** |
| Bottle Size ++ | Dia.15~90 mm/ Height 30~160 mm |
| Label Type + | Non Transparent |
| Label Size ++ | H 10~100mm W 20~300mm |
| Label Reel | ID 75 / OD < 300 mm |
| Accuracy | +/- 1% |
| Power Supply | 10VAC or 220VAC, Single Phase |
| Machine Size | L1800 x W1540 x H1824 mm |
| Machine Weight | 100 kg |
* Subj to Testing ** Subj to Product Types & Sizes *** Customizable + Transparent Subj to Different Sensor Charge ++ Non Standard Sizes Subj to Additional Charge | |
22 / 23
23 / 23
Labeling: 3 Sides Labeler
Model No.LD3055
Applying labels from the side to cover three sides of a container. Controlled by microprocessor and electronic sensing system.
| Speed | 40 PPM * |
| Bottle Size ++ | Dia. 20~100 mm/ Height 25~80mm |
| Label Type + | Non Transparent |
| Label Size ++ | W10~100 x H20~300 mm |
| Label Reel | ID 75 / OD < 300 mm |
| Accuracy | +/-1 mm |
| Power Supply | 110VAC or 220VAC, Single Phase |
| Machine Size | L2100 x W1380 x H1500 mm |
| Machine Weight | 125 kg |
* Subj to Testing ** Subj to Product Types & Sizes *** Customizable + Transparent Subj to Different Sensor Charge ++ Non Standard Sizes Subj to Additional Charge | |
